Water jet cutting machine is an industrial tool capable of cutting a wide variety of materials using a very high-pressure jet of water and abrasive. It is the most versatile cutting machine, which is able to provide through cut in almost any material. The highly pressurized water stream is forced through a tiny hole which carries abrasive garnet to erode away the material. It can be used to cut steel, stainless steel, aluminum, titanium, marble, granite, tile ceramic, glass, rubber, foam and many other materials.
The overall structure design of the cutting platform is reasonable.
Al Tayeb company’s compact and exquisite 2mx1m model. It is open design which is much more easier for material loading and unloading. The water tank bearing platform and structure are separated which ensures the solid mechanical structure during cutting process. If your work piece is smaller or factory space is limited, this model is good for you.
Specifications:
High Pressure Pump:
Our classical product. It can be used for most materials cutting such as metal, stone, glass, wood and so on.It can cut steel up to 100mm. Adopting the advanced design concept and structure design, equipped with imported high-quality supercharger and automatic variable displacement oil pump. After tens of thousands of customer verification, it is the most popular model.
Specifications:
Main Motor Power: 50HP/37KW
Max. Working Pressure: 410Mpa/60,000PSI
Continuous Working Pressure: 360-380Mpa
Max. Water Discharge: 3.7L/min
Max. Orifice Available: 0.3mm
Power Supply: 380V/50Hz/3PH
Noise Level: 75db(A)
Cutting Water System:
Min. Inlet Cutting water: 16L/min
Min. Inlet Cutting Water Pressure: 0.24Mpa
Accumulator Volume: 1.2L
Hydraulic System:
Max. Hydraulic Pressure: 20Mpa/2,900PSI
Oil Tank Capacity: 114L
Cooling System:
Min. Inlet Cooling Water: 12L/min
Min. Inlet Cooling Water Pressure: 0.3Mpa
CNC Waterjet Software
Features
• Italain ECS Touch Screen
• 15 Inch LCD Monitor
• ECS control system from Italy
• Windows 10 operating system
• Bus motion control
• Support DXF and NC code file
•Stop and continue process function
•Able to set the best starting position
•Able to cut from any component
•ShapeCAMM software integrated
•Muliti-language operating interface
Auto Abrasive Delivery System
Max. Inlet Air Pressure：0.8Mpa
Min. Inlet Air Pressure：0.2Mpa
Abrasive Capacity：270Kg
Operating Air Flow：0.5 m3/min
Volume：590x590x1340mm
Power Supply：GC24V
Features
Self-feeding Control
Self sealing
Air Valve to prevent jams and breakages
Use non-metallic sensor to work acutely and long work life.
3 Axis Cutting Head:
Most standarded 3 axis cutting head, no tilting angle cutting, USA imported curcial parts, nozzle and orifice. Good workmanship to ensure the consentricity of the abrasive pipe and gemstone. The Al Tayeb cutting head consist of pure water cutting head and abrasive water cutting head to meet your versatile cutting applications.
